LD-T Series

Tube Fiber Laser Cutting Machine


Ultimate Performance

Front and rear chuck support design, automatic center adjustment,
suitable for all kinds of pipes


Strong Clamping

Pneumatic chuck for stable tube feeding. The chuck has high
positioning accuracy, with a positioning accuracy of less than ±30”


All Kinds of Pipes

Pipe cutting expert, capable of cutting most special-shaped pipes such
as round pipes, square pipes, rectangular pipes and oval pipes


Intelligent Bus Cutting System

Further improve the speed and efficiency of the frog jump function, integrate fast and intelligent perforation mode, fast and intelligent knife collection mode, the system runs smoothly and efficiently

Technical Parameter

Machine model

S3-6522

S5-6522

S6-7528

S8-12036

Chuck speed

S3-6522: 120rpm

S5-6522: 120rpm

S6-7528: 75rpm

S8-12036: 60rpm

Min.Tailstock

S3-6522: 70mm

S5-6522: 70mm

S6-7528: ≥0

S8-12036: ≥0

Working area

S3-6522: 6000mm*φ15-230mm

S5-6522: 6000mm*φ15-230mm

S6-7528: 7000mm*φ15-280mm

S8-12036: 12000mm*φ20-360mm

X/Y axis positioning accuracy

+0.05mm/m

Laser power

S3-6522: 1000w-6000w

S5-6522: 1000w-6000w

S6-7528: 3000w-12000w

S8-12036: 3000w-12000w

Max.running speed

60m/min

Sample Display
